Rated value
+ Voltage: 0.1 ~ 18V / 0.1 ~ 150V
+ Current: 0 ~ 0.6A/ 0 ~ 3A/ 0 ~ 20A
+ Power: 0 ~ 30W/ 0 ~ 150W
Set resolution
+ Voltage: 1mV/10mV
+ Current: 0.1mA/0.1mA/1mA
+ Power:10mW
+ Resistance: 16 bit
Readback resolution
+ Voltage: 0.1mV
+ Current: 0.1mA/0.1mA/1mA
+ Power: 10mW
Set accuracy
+ Voltage: ±(0.025%+0.025%FS)
+ Current: ±(0.1%+0.1%FS) / ±(0.05%+0.05%FS) / ±(0.05%+0.05%FS)
+ Power: 0.2%+0.2%FS
Readback accuracy
+ Voltage: ±(0.025%+0.025%FS)
+ Current: ±(0.1%+0.1%FS) / ±(0.05%+0.05%FS)
+ Power: ±(0.2%+0.2%FS)
Dynamic response
+ Rising: 0.0001~0.06A/µs; 0.0001~0.3A/µs; 0.001~2A/µs
+ Falling: 0.0001~0.06A/µs; 0.0001~0.3A/µs; 0.001~2A/µs
+ Min.rising time: ≒10µS
AC parameter
+ Voltage: 110V ±10% or 220V ±10%
+ Frequency: 50/60Hz
+ Imax.: 0.3A
+ Power factor: /
Interfaces: LAN，USB，RS232
Working temperature: 0 ~ 40℃
Dimension(mm): 82mm*183mm*573mm
N.W.: 5 kg
