ITECH IT6162B ການສະຫນອງພະລັງງານ DC ທີ່ມີຄວາມຖືກຕ້ອງສູງຂອງໂຄງການ (20V, 50A)
DC output range:
+ Voltage: 0~20V
+ Current: 0~50A
Power: 1000W
Line regulation:
+ Voltage: ≤0.02%+2mV
+ Current: ≤0.1%+2mA
Load regulation:
+ Voltage: ≤0.01%+2mA
+ Current: ≤0.1%+10mV
Ripple and noise (20HZ-207MHZ):
+ Voltage: ≤ 4mVp-p / 1.2 mV rms
+ Current: ≤15mArms
Programming resolution:
+ Voltage: 1mV
+ Current: 1mA
Programming accuracy (Within 12 months, 25℃±5℃) (％of Output+Offset):
+ Voltage: ≤0.02%+2mV
+ Current: ≤0.1%+25mA
Display value resolution:
+ Voltage: 1mV
+ Current: 1mA
Read back accuracy (Within 12 months, 25℃±5℃) (％of Output+Offset):
+ Voltage: ≤0.02%+2mV
+ Current: ≤0.05%+15mA
Rise time (no load): ≤1ms
Rise time (full load): ≤1ms
Fall time (no load): ≤50ms
Fall time (full load): ≤1ms
Dynamic response time: ≤200us
Protective function: OVP/OCP/OTP
Communication Interface: GPIB/USB/RS232
Size (WxHxD): 483 x 88.4 x 664.1 mm
Weight: 30kg
