ITECH IT-M3144 ເຄື່ອງຈົດພະລັງງານ DC ທີ່ສາມາດຕັ້ງໂປຣແກຣມໄດ້ (300V/20A/3000W)
Rated Output Value
Voltage: 0～300V
Current: 0～20A
Power: 0～3000W
Power Regulation (%of Output+Offset)
Voltage: 0.001%+10mV
Current: ≤8mA
Power Regulation (%of Output+Offset)
Voltage: 0.004%+20mV
Current: ≤10mA
Setup Resolution
Voltage: 10mV
Current: 1mA
Power: 0.1W
Readback Resolution
Voltage: 10mV
Current: 1mA
Setting Accuracy
Voltage: ≤0.03% + 0.02%F.S.
Current: ≤0.1% + 0.1%F.S.
Power: ≤0.5%F.S.
Readback Accuracy
Voltage: ≤0.03% + 0.02%F.S
Current: ≤0.1% + 0.1%F.S.
Power: ≤0.5%F.S.
Ripple（20hz-20Mhz）
Voltage: typical value≤300 mV(MAX: ≤300mV)
Current: typical value≤20mA(MAX: ≤20mA)
Efficiency: 91%
Remote Sense Compensation Voltage: ≤3V
Command Response Time: 5ms
Power Factor: 0.99
Maximum Input Current: 20A
Maximum Input Apparent Power: 3700VA
Isolation(output to ground): 600VDC
Isolation(input to ground): 2200VDC
Dimension(mm): 255W*530D*109H
Net.Weight: （8±1）kg
