Basic
Resolution: 1280 × 960
Max. Frame rate: 20 fps
Shutter Mode: Global
Mono/Color: Mono
Trigger Mode: Software trigger/External trigger/Free run modes
Software: EasyID
Certifications: CE，KC
Function:
lD: Code 39/Code 93/Code128/CodaBar/EAN8/EAN13/UPCA/UPCE/ITF25/2of5（Industrial2of5）/standard25/GS1-128 etc. and 2D: Data Matrix/MQR/GS1 DM/GS1QR etc.;
Quality Evaluation: ISO/IEC 29158(AIM-DPM), ISO/IEC 15415, ISO/IEC 15416）
Performance
Focal Length: 6.72mm
Working Distance: 35-150 mm
Field of View: 26 × 20 mm - 88 × 66 mm
Max. Read Speed: 20 codes/s
Min. Resolution: 1D: 0.05mm/2D: 0.09mm
Focus Control: Manual control
Light Source Type: Red/white dual light
Port
Connector: Industrial M12 connector, support Ethernet and GPIO
Network Port: 100M Ethernet
GPIO Interface: RS232, 1Opto-isolated input, 1Opto-isolated output,1configurable input/output
Communication Mode: RS232, Ethernet
Communication protocol: SDK，TCP Client，TCP Server，FTP，RS232，Profinet、Modbus、EtherNet/IP、MC(SLMP)、FINS/UDP、FINS/TCP
LED Indicator: Power, Ethernet, Result
Power
Power Supply: 9~26VDC, 0.5A input, suitable for industrial environment
Power Consumption: ＜2.0 W
Structure
Product Dimensions: 50 mm × 50 mm × 28 mm(cable not included)
Net Weight: <130 g
Protection: IP65
Casing Material: Aluminum alloy + front cover
Environment
Operating Temperature: -20℃～+50℃
Operating Humidity: 20%～95%(no condensation)
Storage Temperature: -30℃～+70℃
