Basic
Resolution: 1280 × 960
Max. Frame rate: 20 fps
Shutter Mode: Global
Mono/Color: Mono
Trigger Mode: Support Software Trigger/Hardware Trigger/Free Run, etc.
Software: EasyID
Certifications: CE，KC
Function:
lD: Code 39/Code 93/Code128/CodaBar/EAN8/EAN13/UPCA/UPCE/ITF25/2of5（Industrial2of5）/standard25/GS1-128 etc. and 2D: Data Matrix/MQR/GS1 DM/GS1QR etc.;
Quality Evaluation: ISO/IEC 29158(AIM-DPM), ISO/IEC 15415, ISO/IEC 15416）
Performance
Working Distance: 70mm
Field of View: 42 x 32mm
Max. Read Speed: 20 codes/s
Min. Resolution: 1D code 0.05mm/ 2D code 0.13mm
Light Source Type: Red/white dual light
Port
Connector: Industrial-grade M12 connectors are Ethernet and GPIO interfaces
Network Port: 100M Ethernet
GPIO Interface: 1x RS232 interface, 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output
Communication Mode: RS232, Ethernet
Communication protocol: SDK，TCP Client，TCP Server，FTP，RS232，Profinet、Modbus、EtherNet/IP、MC(SLMP)、FINS/UDP、FINS/TCP
LED Indicator: Power indicator, Network indicator, Result indicator
Power
Power Supply: 9~26VDC, 0.5A input, suitable for industrial environment
Power Consumption: <2.0W
Structure
Product Dimensions: 50mm x 50mm x 28mm (Without cable)
Net Weight: <130 g
Protection: IP65
Casing Material: Aluminum alloy + Front cover
Environment
Operating Temperature: -20℃～+50℃
Operating Humidity: 20%～95%, Non condensing
Storage Temperature: -30℃～+70℃
