Basic
Resolution: 1280 × 1024
Max. Frame rate: 60 fps
Shutter Mode: Global
Lens Mount: M8
Trigger Mode: Support multiple trigger modes such as software trigger/external trigger/free run;
Software: EasyID
Certifications: CE，KC
Function:
lD: Code 39/Code 93/Code128/CodaBar/EAN8/EAN13/UPCA/UPCE/ITF25/2of5（Industrial2of5）/standard25/GS1-128 etc. and 2D: Data Matrix/MQR/GS1 DM/GS1QR/PDF417 etc.;
Quality Evaluation: ISO/IEC 29158(AIM-DPM), ISO/IEC 15415, ISO/IEC 15416）
Focal Length: 4.8 mm
Focus Control: Fixed
Light Source Type: Red/white dual light
Performance
Working Distance: 110 mm
Field of View: 81 × 65 mm
Max. Read Speed: 31 codes/s
Min. Resolution: 1D code 0.07mm / 2D code 0.16mm
Sight: Red light indication
Port
Connector: Industrial-grade M12 connectors are Ethernet and GPIO interfaces
Network Port: 100M Ethernet
GPIO Interface: 1× RS232 interface, 1× Opto-isolated input, 1× Opto-isolated output, 1 configurable input and output
Communication Mode: RS232, Ethernet
Communication protocol: SDK, TCP Client, FTP, TCP Server, RS232, Profinet, Modbus, EtherNet/IP, MCUdp, MCTcp, FinsUDP, FinsTCP, MELSEC
LED Indicator: Power indicator, Network indicator, Result indicator
Power
Power Supply: Support DC 9V～26V wide range voltage input
Power Consumption: <2.5W
Structure
Product Dimensions: 50mm × 50mm × 28.5mm (Without cable)
Net Weight: ＜130 g
Protection: IP65
Casing Material: Aluminum alloy + Front cover
Environment
Operating Temperature: -20℃～+50℃
Operating Humidity: 20%～95%, Non-condensing
Storage Temperature: -30℃～+70℃
