Basic
Sensor: customization
Image Sensor: 29.9 mm × 16.0 mm CMOS
Shutter: Global
Resolution: 9280 × 4992
Frame Rate: 17.5 fps
Bit Depth: 12
Mono/Color: Color
Pixel Size: 3.2 μm × 3.2 μm
Pixel: 50MP
S/N Ratio: 40dB
WDR: 66dB
Image Format: BayerGB8
ROI: Support
Y Flip: Support
Gain: 1~32
Gamma: From 0 to 4, support LUT
Exposure Time: 16μS~15S
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 512MB data storage
Port
Port: CameraLink
GPIO Interface: 3x Opto-isolated input, 3x Opto-isolated output, 1x RS232
Lens Mount: M58 x 0.75
Power
Power Supply: DC 24V power supply via 12 Hirose interface
Power Consumption: 24V≈6.83W
Structure
Product Dimensions: 72mm*72mm*65mm(Non including rear case connector)
Net Weight: 490 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
