Basic
Sensor: GMAX0505
Image Sensor: 1.1" CMOS
Shutter: Global
Resolution: 5120 × 5120
Frame Rate: 41 fps
Bit Depth: 12 bit
Mono/Color: Mono
Pixel Size: 2.5 μm × 2.5 μm
Pixel: 25 MP
S/N Ratio: 40 dB
WDR: 63 dB
Image Format: Mono8/10/10Packed/12/12Packed
Decimation: Support
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1 ~ 32
Gamma: 0 ~ 4，support LUT
Exposure Time: 35 μs ~ 15 s
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 1 GB
Port
Port: 10GigE
GPIO Interface: 3× Opto-isolated input, 3× Opto-isolated output, 1× RS232
Lens Mount: C-mount
Power
Power Supply: DC 24V power supply via 12-pin Hirose interface
Power Consumption: 24 V ≈ 19.4 W
Structure
Product Dimensions: 72 mm × 72 mm × 85.1 mm (not including rear case connector)
Net Weight: 600 g
Environment
Storage Temperature: -30℃ ~ 80℃
Operating Temperature: 0℃ ~ 50℃
