Basic
Sensor: IMX428
Image Sensor: 1.1''CMOS
Shutter: Global
Resolution: 3208 × 2200
Frame Rate: 17 fps
Bit Depth: 12
Mono/Color: Mono
Pixel Size: 4.5 μm × 4.5 μm
Pixel: 7.06MP
S/N Ratio: >38dB
WDR: 70dB
Image Format: Mono8/10/10Packed
Binning: Support
ROI: Support
X Flip: Support
Y Flip: Support
Gain: 1~32
Gamma: From 0 to 4, support LUT
Exposure Time: 1μS~1S
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
SPC: Support
Performance
User Setting: Support two sets of user-defined configurations
Image Buffer: 64MB
Port
Port: GigE,PoE
GPIO Interface: 1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output
Lens Mount: C-mount
Power
Power Supply: PoE/ DC 9V~24V power supply via Hirose interface
Power Consumption: 12V≈3.2W
Structure
Product Dimensions: 29mm*44mm*58mm (not including lens mount and rear case connector)
Net Weight: 100 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
