Basic
Sensor: Gpixel
Image Sensor: 1.1"CMOS
Shutter: Global
Resolution: 5120 × 5120
Frame Rate: 30 fps
Bit Depth: 10
Mono/Color: Mono
Pixel Size: 2.5 μm × 2.5 μm
Pixel: 25 MP
S/N Ratio: ＞35 dB
WDR: ＞64 dB
Image Format: Mono8/10
ROI: Support
Y Flip: Support
Gain: 1~32
White Balance: Support
Exposure Time: 35 μs~1 s
Trigger Mode: Software Trigger/Hardware Trigger/Free Run Mode
Performance
User Setting: Support two sets of user-defined configurations
Pixel Clock: 34M/51M/68M/85M
Port
Port: CameraLink
GPIO Interface: 1x 6 pin Hirose: 1x Opto-isolated input, 1x Opto-isolated output, 1 configurable input and output
Lens Mount: C-mount
Power
Power Supply: PoCL/DC 9V~24V power supply via Hirose interface
Power Consumption: ≈4 W
Structure
Product Dimensions: 29 mm × 44 mm × 58 mmmm(not including lens mount and rear case connector)
Net Weight: 100 g
Environment
Storage Temperature: - 30℃~+80℃
Operating Temperature: - 30℃~+50℃
