Approvals: II 2G Ex ia IIC T4 Gb (-20°C ≤ Ta ≤ +50°C); II 3G Ex nA IIC T4 (-40°C ≤ Ta ≤ +50°C); Baseefa05ATEX0277X; IECEx BAS 06.0057X
Ingress Protection: Designed to IP65; Sensor IP54
Power: 5-28 VDC, max 130 mA
Output: 4-20 mA (requires 8-35 VDC power supply); for IS requirements: 8-30 VDC
Range: 0-10 ppm; 0-100 ppm; 0-1000 ppm (user selectable)
Sampling: Diffusion (can be pumped using an adaptor if required)
Display: 7-segment, 4-digit LCD; 4-color LEDs
Response: Sensor T90 < 5 sec
Accuracy: 0-100 ppm: ±5% at calibration point; 100-1000 ppm: ±10% at calibration points
Calibration: Access via magnetic switch; 100 ppm Isobutylene via calibration kit accessory
Temperature: Operating -20°C to +50°C (-4°F to 122°F); Humidity 0-95% RH (non-condensing)
Weight & Dimensions: Instrument 1.4 kg; Packed 1.6 kg; Dimensions 188 × 126 × 78 mm
4–20 mA Alarm Levels: Selectable 2 mA and 3.5 mA options
