Measuring Range: 0 - 20000 mm
Working Frequency: 0.4 - 20 MHz
Material Velocity: 20 - 20000 m/s
Pulse Repetition Frequency: 60 - 1000 Hz
Gain Range: 0 - 110 dB (Steps: 0.1, 1.0, 2.0, 6.0, 12 dB)
Dynamic Range: ≥32 dB
Vertical Linearity Error: ≤2.0%
Horizontal Linearity Error: ≤0.1%
Resolving Power: >36 dB
Sensitivity Margin: >62 dB (with Ø2 mm flat-bottom hole)
Rectification: Positive, Negative, Full-Wave, RF
Suppression (Reject): 0 - 90%
Noise Level: ≤10%
Pulse Voltage: 50V, 100V, 200V, 400V (Selectable)
Pulse Width: 50 ns - 1000 ns (Adjustable)
Damping: 50Ω / 500Ω (Selectable)
Display: 5.0" TFT Color LCD Touchscreen (800x480 pixels)
Gates: 2 independent gates (peak or flank measurement)
Alarms: Threshold positive/negative, DAC curve alarm (audible and visual)
Interfaces: BNC, USB-C, VGA
Power Supply: Rechargeable Li-ion Battery (>8 hours working time)
Dimensions (L×W×H): 180 × 110 × 45 mm
Weight: 0.68 kg
