Specification
Optical lens: Ø100mm dual-telecentric lens
Measurement range: 100x80mm
Measurement accuracy:
Axial: ±(5+L/20)µm
Radial: ±(3+D/20)µm
Repeatability:
Axial: ±2µm
Radial: ±1µm
Illumination system:
Transmission light: telecentric illuminator, green light
Surface light (optional): high angle ring, white light
Max. weight of workpiece: 3kg
Measurement time: <2s
Environmental requirement: 2D measurement
Measurement data: temperature: 20°C±2°C, relative humidity: 30%-80%, vibration: <0.002g, less than 15Hz
Power supply: 220V, 50Hz, 600W
Dimension (LxWxH): 790x230x385mm
Weight: 27kg
Standard delivery:
Main unit: 1pc
Computer: 1pc
Software: 1pc
