INSIZE ISQ-S600 ຕົວກໍານົດຄວາມຍາວ (motorized) (inter diameter: 0.1~600mm; outer diameter: 40~640mm)

Range:

- inter diameter: 0.1~600mm

- outer diameter: 40~640mm

Resolution: 0.5µm

Accuracy: (1.5+L/500)µm

Repeatability: 0.8µm

Zeroing method: motorized

Interface: ETHERNET, USB

Environment requirement: temperature: 10~35°C, temperature change: ≤1°C/h

Power: 100~240V

Weight: 140kg

■ Used to set and calibrate various measuring tools,

such as bore gauges, multifunctional calipers, internal/external snap gauges, three-point internal micrometers, tubular inside micrometers, calipers, micrometers, etc

■ Manual mode can be used to measure workpieces

■ Stores up to 100 positions (OD + ID)

■ Can preset any position and save it

■ Can set the step distance and move continuously

■The built-in steel strip grating ruler has the same temperature expansion coefficient as the steel workpiece, so length presetters can be used in workshops

■ Connect the upper computer and MES system through Modbus protocol
