Specification
Optical geometry: D/8 (diffused illumination/8° direction reception) SCI+SCE (specular component included+specular component excluded)
Integrating sphere size: Ø40mm
Lighting source: full-band balanced LED + xenon lamp
Sensor: dual-row high-precision CMOS image sensor
Calibration mode: BCRA certified black and white board energy calibration, green board wavelength accuracy calibration
Spectrophotometric mode grating: grating
Display accuracy: 0.01
Light source lifetime: 10 million times measurements
Wavelength range: 360nm~780nm
Wavelength interval: 10nm
Measurement range: 0~200%
Reflectance resolution: 0.01%
Measuring aperture: Ø11mm, Ø10mm, Ø6mm, Ø3mm
Repeatability: 0.01 ΔE*ab (after instrument calibration, the white board was measured 30 times at 5s intervals with the MAV calibre) 0.2 ΔE*ab (BCRA series II 12 colour plates MAV calibre measurement average)
Inter-instrument error: 0.2 AE*ab (đo trung bình của 12 tấm màu BCRA series II với thước đo MAV)
Observer angle: 2°/10°
Colorimetric index:
Spectral reflectivity, CIE-Lab, CIE-LCh, HunterLab, CIE-Luv, XYZ, Yxy, RGB (ΔE*ab, ΔE*cmc, ΔE*94, ΔE*00)
Whiteness (ASTM E313-00, ASTM E313-73, CIE, ISO2470/R457, AATCC, Hunter, Taube Berger Stensby)
Yellowness (ASTM D1925, ASTM E313-00, ASTM E313-73), Blackness (My, dM), Strength, Fastness
Tint (ASTM E313-00), CMYK (A, T, E, M), Milm, Munsell, Opacity, Color strength
Illuminantion: A, B, C, D50, D55, D65, D75, F1, F2, F3, F4, F5, F6, F7, F8, F9, F10, F11, F12, CWF, U30, U35, DLF, NBF, TL83, TL84, ID50, ID65, LED-B1, LED-B2, LED-B3, LED-B4, LED-B5, LED-BH1, LED-RGB1, LED-V1, LED-V2
Measuring time: 1s
Date storage: instrument: 10000 pcs, app: mass storage
Locating method: color camera preview
Display screen: 3.5-inch full-colour screen, capacitive touch screen
Interface: USB, bluetooth
Calibration: automatic intelligent calibration
Software support: Andriod, iOS, Windows
Power: Li-ion battery, 7.2V, 3000mAh, fully charged continuous test 8000 times
Dimension: 233X77X93mm
Weight: 600g
Standard delivery
Main unit: 1pc
Calibration cavity: 1pc
Software and USB cable: 1pc
Measuring aperture: 4pcs
Power adapter: 1pc
- The wavelength range of conventional spectrophotometer is 400~700nm, for more accurate colour measurement, the wavelength of this spectrophotometer is extended to 360-780nm
- Xenon lamp and LED light system for longer than expected life
- Four aperture sizes can be switched at will, allowing for easy measurement of even the smallest objects or curved samples
Automatic wavelength accuracy correction using reference grade BCRA green boards
- No need to manually calibrate, just put it on the calibration base, the instrument will be automatically calibrated according to its own state and environmental factors, to ensure that the
instrument is always in a stable state
- Built-in colour camera to take the view of the positioning, accurate determination of the object to be measured part
- Single measurement, continuous uninterrupted measurement, averaging possible
