INSIZE 2165-60 ເສັ້ນຜ່າສູນກາງຂອງກະທູ້ / ແກນສະກູສະກູ (40-60mm)

  • ຜູ້ຜະລິດ:INSIZE
    Model: 2165-60
  • ຕິດຕໍ່ພົວພັນ
    • ຂໍໃບສະເໜີລາຄາ

Range: 40-60mm

Accuracy: ±5μm

A: 152mm

B: 138mm

C: 46mm

L: 100mm

Ball tip diameter can be customized according to workpieces. Diameter of trapezoidal screw or external thread ball tips:

ØD=0.5 x pitch P/cos (thread angle a/2).

Ball tips diameter ØD of ball screw is corresponding steel ball specification

Probe retracting range: 3mm, measuring force: 20N Repeatability: 2μm

ລາຍລະອຽດ

■ Measure the pitch diameter of lead screw and external thread

■ Optional accessory: 0.001mm digital/dial indicators
