Infineon TLE4966L ຕິດຕັ້ງຕຳແໜ່ງແລະກວດສອບກະວດໄຟຟ້າ High Precsn Hall Effect Switch

Unit Weight: 6.622 g

Qualification: AEC-Q100

Mounting Style: Through Hole

Output Voltage: 18 V

Supply Voltage - Max: 18 V

Supply Voltage - Min: 2.7 V

Maximum Output Current: 10 mA

Pd - Power Dissipation: 72 mW

Operating Point Min/Max: 5.2 mT to 10.3 mT

Operating Supply Current: 7 mA

Operating Supply Voltage: 15 V

Release Point Min/Max (Brp): - 10.3 mT to - 5.2 mT

Maximum Operating Temperature: + 150 C

Minimum Operating Temperature: - 40 C
