Fall Time: 15 ns
Rise Time: 22 ns
Technology: Si
Channel Mode: Enhancement
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel Power MOSFET
Qg - Gate Charge: 127 nC
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 250 W
Vgs - Gate-Source Voltage: - 10 V, + 10 V
Typical Turn-On Delay Time: 25 ns
Typical Turn-Off Delay Time: 53 ns
Id - Continuous Drain Current: 475 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 330 S
Rds On - Drain-Source Resistance: 600 uOhms
Vds - Drain-Source Breakdown Voltage: 40 V
Vgs th - Gate-Source Threshold Voltage: 2.1 V
