Fall Time: 6.1 ns
Rise Time: 5.8 ns
Technology: SiC
Channel Mode: Enhancement
Configuration: Single
Mounting Style: Through Hole
Transistor Type: 1 N-Channel
Qg - Gate Charge: 39 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 218 W
Vgs - Gate-Source Voltage: - 10 V, + 25 V
Typical Turn-On Delay Time: 4.8 ns
Typical Turn-Off Delay Time: 10.6 ns
Id - Continuous Drain Current: 48 A
Maximum Operating Temperature: + 175 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 12 S
Rds On - Drain-Source Resistance: 40 mOhms
Vds - Drain-Source Breakdown Voltage: 1.2 kV
Vgs th - Gate-Source Threshold Voltage: 5.1 V
