Fall Time: 4.8 ns
Rise Time: 4.8 ns
Technology: Si
Unit Weight: 38.760 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 18 nC
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 69 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 8.5 ns
Typical Turn-Off Delay Time: 25.6 ns
Id - Continuous Drain Current: 40 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 32 S
Rds On - Drain-Source Resistance: 4.4 mOhms
Vds - Drain-Source Breakdown Voltage: 60 V
Vgs th - Gate-Source Threshold Voltage: 1.7 V
