Fall Time: 3 ns
Rise Time: 6.5 ns
Technology: Si
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Single
Mounting Style: SMD/SMT
Transistor Type: 1 N-Channel
Qg - Gate Charge: 41 nC
Moisture Sensitive: Yes
Number of Channels: 1 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 144 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 70 ns
Typical Turn-Off Delay Time: 16 ns
Id - Continuous Drain Current: 24 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 40 C
Rds On - Drain-Source Resistance: 115 mOhms
Vds - Drain-Source Breakdown Voltage: 650 V
Vgs th - Gate-Source Threshold Voltage: 4.5 V
