Width: 5.15 mm
Height: 1.27 mm
Length: 5.9 mm
Fall Time: 2.2 ns, 4 ns
Rise Time: 2.8 ns, 5.4 ns
Technology: Si
Unit Weight: 101.880 mg
Channel Mode: Enhancement
REACH - SVHC: Details
Configuration: Dual
Mounting Style: SMD/SMT
Transistor Type: 2 N-Channel
Qg - Gate Charge: 3 nC, 8.8 nC
Number of Channels: 2 Channel
Transistor Polarity: N-Channel
Pd - Power Dissipation: 2.5 W
Vgs - Gate-Source Voltage: - 20 V, + 20 V
Typical Turn-On Delay Time: 3.3 ns, 3.8 ns
Typical Turn-Off Delay Time: 15 ns, 25 ns
Id - Continuous Drain Current: 40 A
Maximum Operating Temperature: + 150 C
Minimum Operating Temperature: - 55 C
Forward Transconductance - Min: 77 S, 130 S
Rds On - Drain-Source Resistance: 3.7 mOhms, 1.3 mOhms
Vds - Drain-Source Breakdown Voltage: 25 V
Vgs th - Gate-Source Threshold Voltage: 1.6 V
