Measurement channels: 1
Display: LCD, LED backlight
Rate 1/s: 10
Connectable gauges with display range
CMR (A/D) : 1 × 10^-3 × FS ... 1 × FS mbar / Torr
PCR: 5 × 10^-4 ... 1500 mbar / 3.75 × 10^-4 ... 1125 Torr
TPR: 5 × 10^-4 ... 1000 mbar / 3.75 × 10^-4 ... 750 Torr
PKR: 1 × 10^-9 ... 1000 mbar / 7.5 × 10^-10 ... 750 Torr
IKR: 1 × 10^-9 ... 1 × 10^-2 mbar / 7.5 × 10^-10 ... 7.5 × 10^-3 Torr
APR: 0.1 ... 55000 mbar / 7.5 × 10^-2 ... 4.125 × 10^4Torr
PBR: 5 × 10^-10 ... 1000 mbar / 3.75 × 10^-10 ... 750 Torr
IMR: 2 × 10^-6 ... 1000 mbar / 1.5 × 10^-6 ... 750 Torr
Measurement unit (selectable): mbar, Torr, Pa, hPa, Micron, V
Setpoints
Setpoint relays: 2
Channel assignment: 1
Adjustment range: sensor dependent
Hysteresis: adjustable
Relay contact: floating changeover contact
Contact rating V (ac) / A: 30 / 1
Contact rating V (dc) / A: 60 / 0.5
Connector: D-sub, 15-pin, female
Analog output
Range V: 0 ... 10.3, sensor analog output signal
Analog output: 1
Connector: Amphenol C91B, 7‑pin, female
Interface (digital): USB slave, master, Ethernet and RS485
Connector: USB Type A (stick), USB Type B, FCC68/RJ45, Binder M12
Power Supply V (ac): 100 ... 240
Frequency Hz: 50 ... 60
Consumption W: ≤45
Operation temperature (ambiance) °C: +5 ... +50
