Stirring quantity max. per stirring position (H2O): 80 l
Motor rating input: 220 W
Motor rating output: 90 W
Motor principle: Brushless DC
Speed display: LED
Speed range: 60 - 1400 rpm
Viscosity max.: 50000 mPas
Output max. at stirring shaft: 90 W
Permissible ON time: 100 %
Torque max. at stirring shaft: 900 Ncm
Torque max. at stirring shaft at 60 1/min (overload): 1144 Ncm
Torque max. at stirring shaft at 100 1/min: 900 Ncm
Torque max. at stirring shaft at 1.000 1/min: 86 Ncm
torque I max.: 900 Ncm
torque II max.: 300 Ncm
Speed range I (50 Hz): 60 - 400 rpm
Speed range II (50 Hz): 240 - 1400 rpm
Speed range I (60 Hz): 72 - 480 rpm
Speed range II (60 Hz): 288 - 1680 rpm
Speed control: stepless
Setting accuracy speed: 1 ±rpm
Deviation of speed measurement: 10 ±rpm
Stirring element fastening: chuck
Chuck range diameter: 1 - 10 mm
Hollow shaft, inner diameter: 10.5 mm
Hollow shaft (push-through - when stopped): yes
Fastening on stand: extension arm
Extension arm diameter: 16 mm
Extension arm length: 145 mm
Speed control: mechanical
Nominal torque: 9 Nm
housing material: alu-cast coating / thermoplastic polymer
Noise without element: 62.5 dB(A)
Dimensions (W x H x D): 123 x 364 x 252 mm
Weight: 7.5 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 40
Voltage: 220 - 240 / 100 - 115 V
Frequency: 50/60 Hz
Power input: 220 W
