Stirring quantity max. per stirring position (H2O): 150 l
Motor rating input: 220 W
Motor rating output: 176 W
Motor principle: Brushless DC
Speed display: TFT
Speed range: 0/6 - 2000 rpm
Intermittent operation: yes
Viscosity max.: 100000 mPas
Output max. at stirring shaft: 167 W
Permissible ON time: 100 %
Torque max. at stirring shaft: 400 Ncm
torque I max.: 400 Ncm
torque II max.: 80 Ncm
Speed range I (50 Hz): 6 - 400 rpm
Speed range II (50 Hz): 30 - 2000 rpm
Speed range I (60 Hz): 6 - 400 rpm
Speed range II (60 Hz): 30 - 2000 rpm
Speed control: stepless
Setting accuracy speed: 1 ±rpm
Deviation of speed measurement n > 300rpm: 1 ±%
Deviation of speed measurement n < 300rpm: 3 ±rpm
Stirring element fastening: chuck
Connection for ext. temperature sensor: PT1000
Temperature display: yes
Plug-in coupling (Ø): 10 mm
Chuck range diameter: 3 - 16 mm
Hollow shaft, inner diameter: 10.3 mm
Hollow shaft (push-through - when stopped): yes
Fastening on stand: extension arm
Extension arm diameter: 16 mm
Extension arm length: 160 mm
Torque display: yes
Speed control: electronic
Nominal torque: 4 Nm
Torque measurement: trend
deviation of torque measurement I: 40 ±Ncm
deviation of torque measurement II: 12 ±Ncm
Timer: yes
Timer display: TFT
Time setting range: 1 - 6000 min
Temperature measuring range: -10 - +350 °C
Temperature measurement resolution: 0.1 K
Accuracy of temperature measurement: ±0.05 + tolerance PT1000 (DIN IEC 751 Class A) K
Limit deviation temperature sensor: ≤ ± (0.15 + 0.002xITI) K
housing material: alu-cast coating / thermoplastic polymer
communication distance (depend onbuilding) max. 150 m
Dimensions (W x H x D): 114 x 320 x 268 mm
Weight: 8.2 kg
Permissible ambient temperature: 5 - 40 °C
Permissible relative humidity: 80 %
Protection class according to DIN EN 60529: IP 40
RS 232 interface: yes
USB interface: yes
Voltage: 230 / 115 / 100 V
Frequency: 50/60 Hz
Power input: 226 W
