Voltage: 150V
Current: 60A
Power: 2.4kW
CC Mode:
Range: 0~6A/ 0~60A
Setting Accuracy (23±5℃): 0.05%+0.1%F.S.
CV Mode:
Range: 0~15V/ 0~150V
Setting Accuracy (23±5℃): 0.05%+0.05%F.S.
CP Mode:
Range: 0~2.4kW
Setting Resolution: 0.1W
Setting Accuracy (23±5℃): 0.5%+1%F.S.
Voltage Measurement:
Range: 0~15V/ 0~150V
Readback Accuracy(23±5℃): 0.05%+0.05%F.S.
Current Measurement:
Range: 0~6A/ 0~60A
Readback Accuracy(23±5℃): 0.05%+0.1%F.S.
Power Measurement:
Range: 0~2.4kW
Readback Accuracy(23±5℃): 0.5%+1%F.S.
Dynamic Mode:
T1&T2: 0.015~60000ms
Resolution: 1μs/1ms
Accuracy (23±5℃): ≤20μs+100ppm
Others:
Interface: LAN/RS232/CAN
AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz
Communication Response Time: ≤10ms
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Size: 19inch/3U
