Voltage: 10V
Current: 1800A
Power: 6000W
Min. Operating Voltage: -3V@1800A
CC Mode:
Range: 0~180A/ 0~1800A
Setting Resolution: 10mA/ 100mA
Setting Accuracy (23±5℃): 0.05%+0.05%F.S.
CV Mode:
Range: 0~5V/ 0~10V
Setting Resolution: 0.1mV/ 1mV
Setting Accuracy (23±5℃): 0.025%+0.025%F.S.
CP Mode:
Range: 6000W
Setting Resolution: 100mW
Setting Accuracy (23±5℃): 0.1%+0.1%F.S.
Voltage Measurement:
Range: -3~5V/ -3~10V
Readback Accuracy (23±5℃): 0.025%+0.025%F.S.
Current Measurement:
Range: 0~180A/ 0~1800A
Readback Accuracy (23±5℃): 0.05%+0.05%F.S.
Power Measurement:
Range: 6000W
Readback Accuracy (23±5℃): 0.1%+0.1%F.S.
T1&T2: 0.015ms~60000ms
Resolution: 1μs/1ms
Accuracy (23±5℃): 1μs+100ppm/1ms+100ppm
Others:
Protection: OVP/OCP/OPP/OTP
Interface: LAN/RS232/CAN
Communication: Modbus-RTU protocol, SCPI protocol
Protocol:
AC Input: 3-phase 5-wire wiring, AC 380V/50Hz
Communication Response Time: ≤10ms
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Operating Temperature: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Dimension: Cabinet 22U*600.0(W)*800.0(D)mm
