Voltage: 150V
Current: 150A
Power: 1800W
Min operating voltage: 2V@150A
CC mode
Range: 0~15A/ 0~150A
Setting Resolution: 1mA/ 10mA
Setting Accuracy (23±5℃): Low range:0.1%+0.1%F.S.,/ High range:0.1%+0.15%F.S
CV mode
Range: 0~15V/ 0~150V
Setting Resolution: 1mV/ 10mV
Setting Accuracy: (23±5℃) 0.05%+0.1%F.S.
CP mode
Range: 0~1800W
Setting Resolution: 10mW
Setting Accuracy (23±5℃): 0.5%+1%F.S
CR mode
Range: 0.02~100Ω/ 0.4~1000Ω
Setting Resolution: 16 bits
Setting Accuracy (23±5℃): 0.35%+31.25mS/ 0.35%+3.1mS
Slew Rate
Current: 2.5~150A/ms/ 150~7500A/ms
Voltage: 10~60V/ms/ 60~600A/ms
Power:2.5~150A/ms/ 150~7500A/ms
Resistance: 2.5~150A/ms/ 150~7500A/ms
Voltage Measurement
Range: 0~15V/ 0~150V
Readback Accuracy (23±5℃): 0.05%+0.05%F.S.
Current Measurement
Range: 0~15A / 0~150A
Readback Accuracy (23±5℃):0.05%+0.1%F.S.
Power Measurement
Range: 0~1800W
Readback Accuracy (23±5℃): 0.5%+1%F.S.
Interface: LAN/RS232
AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz
Sampling Frequency: 25Hz
Communication Response Time: ≤10ms
Operating Environment: Altitude: <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Net weight: Approx. 16kg
Dimension: 2U, 88.0(H)*482.0(W)with handle*507.0(D)mm
