Voltage: 600V
Current: 30A
Power: 900W
Min. Operating Voltage: 0.6V@3A/ 1.5V@30A
Channels: 2CH
CV Mode:
Range: 0~60V/ 0~600V
Setting Resolution: 1mV/ 10mV
Setting Accuracy (23±5℃): 0.025%+0.025%F.S.
Readback Resolution: 0.1mV/ 1mV
Readback Accuracy (23±5℃): 0.025%+0.025%F.S.
CC Mode:
Range: 0~3A/ 0~30A
Setting Resolution: 0.1mA/ 1mA
Setting Accuracy (23±5℃): 0.05%+0.05%F.S.
Readback Resolution: 10μA/ 0.1mA
Readback Accuracy (23±5℃): 0.05%+0.05%F.S.
CP Mode:
Range: 90W/ 900W
Setting Resolution: 1mW/ 10mW
Setting Accuracy (23±5℃): 0.1%+0.1%F.S.
Readback Resolution: 0.1mW/ 1mW
Readback Accuracy (23±5℃): 0.1%+0.1%F.S.
CR Mode:
Range: 1Ω~80000Ω/ 0.1Ω~8000Ω
Setting Resolution: 1Ω/ 0.1Ω
Setting Accuracy (23±5℃): (Vin/Rset)*0.1%+0.1%IF.S.
Slew Rate:
Current: 0.1~270A/ms/ 0.1~3600A/ms
Power: 0.1~270A/ms/ 0.1~3600A/ms
Resistance: 0.1~270A/ms/ 0.1~3600A/ms
Dynamic Mode (CCD):
T1&T2: 0.016ms~60000ms/0.016s~60000s
Resolution: 1μs/1ms
Rise/Fall Slew Rate: 0.1~270A/ms/ 0.1~3600A/ms
Others:
Protection: OVP/OCP/OPP/OTP/RV
Interface: LAN/RS232/RS485
Communication Protocol: Modbus-RTU protocol, SCPI protocol, TCP/IP, UDP protocol
Communication Response Time: ≤5ms
Ripple Measurement: Bandwidth 10Hz~100kHz
AC Input: Single phase, 100~240V AC, frequency 47Hz~63Hz, current≤1A@220V, current≤2A@110V
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx.18kg
Dimension: 3U, 132.0(H)*482.0(W)with handle*501.0(D)mm
