Voltage: 150V/CH
Current: 6A/CH
Power: 600W/CH
Channels: 4CH
CV Mode:
Range: 0~150V
Setting Resolution: 10mV
Setting Accuracy (23±5℃): 0.05%+0.1%F.S.
Setting Temperature Coefficient: 50ppm/℃
Readback Resolution: 10mV
Readback Accuracy(23±5℃): 0.05%+0.1%F.S.
Readback Temperature Coefficient: 50ppm/℃
CC Mode:
Range: 0~6A
Setting Resolution: 1mA
Setting Accuracy (23±5℃): 0.1%+0.1%F.S.
Setting Temperature Coefficient: 50ppm/℃
Readback Resolution: 1mA
Readback Accuracy (23±5℃): 0.1%+0.1%F.S.
Readback Temperature Coefficient: 50ppm/℃
Voltage Ripple(20Hz-20MHz): ≤300mVp-p; ≤25mVrms
Rise Time(no load): ≤50ms
Fall Time(no load): ≤50ms
Load Regulation: ≤0.03%(Voltage) / ≤0.05%(Current)
Line Regulation: ≤0.015%(Voltage) / ≤0.05%(Current)
Others:
Interface: LAN/RS232
AC Input: Single phase, 220V AC±10%, frequency 47Hz~63Hz
Temperature: Operating temperature: 0℃~40℃, storage temperature: -20℃~60℃
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 10kg
Dimension: 2U, 88.0(H)*482.0(W)with handle*560.0(D)mm
