Voltage: 0.5~81V
Current: 0~6.0A
Power: 100W
CV Mode:
Range: 0.5~81V
Setting Resolution: 10mV
Setting Accuracy: 0.05%+10mV
CC Mode:
Range: 0~6.0A
Setting Resolution: 1mA
Setting Accuracy: 0.2%+2mA
Voltage Measurement:
Range: 0.5~81V
Readback Resolution: 10mV
Readback Accuracy: 0.05%+10mV
Temperature Coefficient: 50ppm/°C
Current Measurement:
Range: 0~6.0A
Readback Resolution: 1mA
Readback Accuracy: 0.2%+2mA
Temperature Coefficient: 50ppm/°C
Line Regulation:
Voltage: <0.01%+3mV
Current: <0.1%+5mA
Load Regulation:
Voltage: ≤20mV
Current: ≤10mA
Dynamic Characteristics:
Voltage Rise Time (no load): ≤300ms
Voltage Rise Time (full load): ≤300ms
Voltage Fall Time (no load): ≤500ms
Voltage Fall Time (full load): ≤200ms
Transient Recovery Time: ≤5ms
Output Ripple&Noise(20Hz-20MHz):
Voltage: ≤10mVrms
Current: ≤8mArms
Others:
AC Input: Single phase, 100~240VAC, frequency 47Hz~63Hz
Operating Environment: Altitude <2000m, relative humidity: ≤80%(non-condensing), atmospheric pressure: 80~110kPa
Storage Temperature: -10°C~70°C，≤70%(non-condensing)
Interface: RS232/RS485/LAN
Net Weight: Approx. 1.8kg
Dimension: 55.0(W)*315.0(D)*140.0(H)mm
