Voltage: 0~40V
Current: 0~50A
Power: 900W
Channels: 1CH
CV Mode:
Range: 0~40V
Setting Resolution: 1mV
Setting Accuracy (23±5°C): ≤0.03%+0.02%F.S.
Voltage Ripple(20Hz-20MHz): ≤40mVp-p
CC Mode:
Range: 0~50A
Setting Resolution: 1mA
Setting Accuracy (23±5°C): ≤0.1%+0.1%F.S.
Current Ripple(20Hz-5MHz): ≤50mArms
CP Mode:
Range: 900W
Setting Resolution: 0.01W
Setting Accuracy (23±5°C): 0.5%F.S.
Voltage Measurement:
Range: 0~40V
Readback Resolution: 1mV
Readback Accuracy (23±5°C): ≤0.03%+0.02%F.S.
Current Measurement:
Range: 0~50A
Readback Resolution: 1mA
Readback Accuracy (23±5°C): ≤0.1%+0.1%F.S.
Line Regulation:
Voltage: <0.02%F.S.
Load Regulation:
Voltage: <0.05%F.S.
Dynamic Characteristics:
Voltage Rise Time(no load): ≤10ms
Voltage Rise Time(full load): ≤10ms
Voltage Fall Time(no load): ≤25ms
Voltage Fall Time(full load): ≤10ms
Transient Recovery Time: The output voltage recovering within 0.5% of the rated output voltage value（10%~90% load)≤2ms
Others:
Isolation(Output to Ground): 500V DC
Max. Efficiency: 0.91
Power Factor: 0.99
Interface: LAN/RS232/RS485/CAN
Communication Response Time: ≤5ms
AC Input: 220V AC±10%,47Hz~63Hz,≤10A
Temperature: Operating temperature: 0°C~40°C, storage temperature: -10°C~70°C
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 5kg
Dimension: 88.0(H)*214.0(W)*413.5(D)mm, with output shield
