Rated Value:
Voltage: 0~20V
Current: 0~1100A
Power: 0~10000W
Channels: 1CH
CV Mode:
Range: 0~20V
Setting Resolution: 1mV
Setting Accuracy (23±5°C): ≤0.03%+0.02%F.S.
Voltage Ripple(20Hz-20MHz): ≤5mVrms; ≤65mVp-p
CC Mode:
Range: 0~1100A
Setting Resolution: 10mA
Setting Accuracy (23±5°C): ≤0.1%+0.1%F.S.
Current Ripple(20Hz-5MHz): ≤300mArms; ≤2000mAp-p
CP Mode:
Range: 10000W
Setting Resolution: 0.1W
Setting Accuracy (23±5°C): 0.5%F.S.
Voltage Measurement:
Range: 0~20V
Readback Resolution: 1mV
Readback Accuracy (23±5°C): ≤0.03%+0.02%F.S.
Current Measurement:
Range: 0~1100A
Readback Resolution: 10mA
Readback Accuracy (23±5°C): ≤0.1%+0.1%F.S.
Line Regulation:
Voltage: <0.02%F.S.
Current: <0.05%F.S.
Load Regulation:
Voltage: <0.03%F.S.
Current: <0.05%F.S.
Dynamic Characteristics:
Voltage Rise Time(no load): ≤10ms
Voltage Rise Time(full load): ≤10ms
Voltage Fall Time(no load): ≤300ms
Voltage Fall Time(full load): ≤10ms
Current Rise Time(no load): ≤10ms
Current Rise Time(full load): ≤10ms
Current Fall Time(no load): ≤10ms
Current Fall Time(full load): ≤10ms
Transient Recovery Time: The output voltage recovering within 0.5% of the rated output voltage value（10%~90% load)≤5ms
Others:
Isolation(Output to Ground): 500V DC
Max. Efficiency: 92%
Power Factor: 0.99
Interface: LAN/RS232/RS485/CAN
Communication Response Time: ≤5ms
AC Input: 340VAC~480VAC,47Hz~63Hz,≤28A
Temperature: Operating temperature: 0°C~40°C, storage temperature: -20°C~60°C
Operating Environment: Altitude <2000m, relative humidity: 5%~90%RH(non-condensing), atmospheric pressure: 80~110kPa
Net Weight: Approx. 30kg
Dimension: 88.0(H)*428.0(W)*688.0(D)mm,with output shield
