Capacity: 60kW
CV: 600V
CC: 100A
AC Input (3Ø 380V 50/60Hz): Power - VA: 75kVA
Line regulation
Voltage: ± 0.04% of full scale
Current: ± 0.08% of full scale
Load regulation
Voltage: ± 0.05% of full scale
Current: ± 0.1% of full scale
Over voltage / Over current setting range: 0% ~ 110% of rated voltage; 0% ~ 110% of rated rated current
Withstand voltage
Primary - Chassis: No abnormalities AC 2000V for 1 minute
Primary - Secondary: No abnormalities AC 2000V for 1 minute
Secondary - Chassis: No abnormalities DC 1200V for 1 minute
Weight: Approx. 580kg
Size: 35UE
Operating Temperature: 0~40℃; 30%~90%RH (no condensation)
Storage environment: -20~70℃; 10%~90%RH (no condensation)
Interface
Standard: Standard GPIB and Isolation RS-485 Interface.
Option: Analog Programming and monitoring, isolated type.
Optional Items:
HP-OPT-RMS: True RMS Current & True Watt
HP-OPT-API: Analog Programming interface
HP-OPT-CP: Constant Power
HP-OPT-IS: Impedance Simulation
HP-OPT-PS: Parallel & Series Controller
