ICOM IC-M85 ເຄື່ອງຮັບສັນຍານທາງທະເລ VHF
Frequency coverage (Tx/Rx):
Marine channels: 156.025–157.425 MHz (Tx), 156.050–163.275 MHz (Rx)
Land mobile channels: 136.000–174.000 MHz
Usable channel groups:
Marine: USA, INT, CAN, WX
Land: 100 land mobile channels
Type of emissions:
Marine: 16K0G3E
Land: 16K0F3E / 11K0F3E
Channel spacing:
Marine: 25 kHz
Land: 25 kHz / 12.5 kHz
Power supply requirement: 7.2 V DC nominal
Antenna impedance: 50 Ω
Operating temperature range:
Marine: –20°C to +60°C (–4°F to +140°F)
Land: –30°C to +60°C (–22°F to +140°F)
Dimensions (W × H × D, projections included): 56 × 92 × 36.2 mm (with BP-294) / 2.2 × 3.6 × 1.4 in
Weight: Approx. 246 g (9.9 oz) with BP-294, FA-SC58V, and MB-93
TRANSMITTER
Max. frequency deviation:
Marine: ±5.0 kHz
Land: ±5.0 kHz (Wide) / ±2.5 kHz (Narrow)
Frequency stability: ±5.0 ppm
Spurious emissions: –70dBc typical
Hum and noise:
Marine: 40 dB (Wide)
Land: 40 dB (Wide) / 34 dB (Narrow)
Audio harmonic distortion: 10% (at 60% deviation)
Modulation limiting: 60 - 100% of maximum deviation
RECEIVER
Sensitivity (at 12 dB SINAD): 0.25 μV typical
Spurious response: 70 dB typical
Intermodulation: 70 dB typical
Audio output power:
Internal speaker: 700 mW typical (at 10% distortion, with 12 Ω load)
External speaker: 700 mW typical (at 10% distortion, with 8 Ω load)
