General Specifications
Prime Power Output (kW): 25
Standby Power Output (kW): 28
Frequency (Hz): 50
Voltage (V): 230
Current (A): 109
ATS Port: Available
Battery: 2 × 60 Ah
Fuel Tank Capacity (L): 115
Coolant Capacity (L): 10.2
Fuel Consumption (at 50% / 100% load): 5.2 / 10.5 L/h
Continuous Operating Time (50% / 100% load): 18 / 11 hours
Noise Level at 7m (dBA): 68
Total Weight (kg): 1030
Dimensions (L × W × H) (mm): 2230 × 930 × 1500
Engine
Model: HY4102
Power Output (kW @1500rpm): 32
Speed: 1,500 RPM
Governing System: Mechanical
Number of Cylinders: 4
Starting Method: Electric Start
Displacement (cc): 3800
Compression Ratio: 18:1
Lubricating Oil Capacity (L): 8.2
Alternator
Model: 184H
Type: Brushless
Continuous Power Output (kW): 25
Power Factor (Cosφ): 1
Insulation Class: H
Protection Class: IP23
Voltage Regulation: Automatic (AVR)
Control & Monitoring System
Control Panel Model: ComAp AMF20
Monitoring Functions:
Current Display: Yes
Frequency Display: Yes
Phase & Neutral Voltage Display: Yes
Power Factor Display: Yes
Automatic Fuel Level Adjustment: Yes
Oil Pressure Warning: Yes
High Coolant Temperature Warning: Yes
Battery Voltage Display: Yes
Engine Speed Display: Yes
Engine Hour Counter: Yes
Supervision Functions:
Output Relay Monitoring: Yes
LCD Brightness Adjustment: Yes
PIN Code Protection: Yes
Multilingual Support: Yes
Protection and Auto Shutdown Functions
High/Low Voltage Alarm: Yes
High/Low Frequency Alarm: Yes
Over/Under Speed Protection: Yes
Low Oil Pressure Alarm: Yes
High Engine Temperature Alarm: Yes
High/Low Battery Voltage Alarm: Yes
Overcurrent Protection: Yes
Start Delay Time Adjustment: Yes
