General Specifications
Prime Power Output: 112 kVA
Standby Power Output: 125 kVA
Frequency: 50 Hz
Voltage: 230/400 V
Current: 161.7 A
ATS Connection Port: Available
Battery: 2 × 55 Ah
Fuel Tank Capacity: 245 L
Coolant Capacity: 24 L
Fuel Consumption at 100% Load: 28 L/h
Continuous Running Time at 100% Load: 9 hours
Noise Level at 7 meters: 72 dBA
Total Weight: 1,970 kg
Dimensions (L × W × H): 3400 × 1000 × 1700 mm
2. Engine
Model: HY6B155LD
Power Output (kW @ 1500 rpm): 103 kW
Speed: 1500 RPM
Governing System: Electronic
Number of Cylinders: 6
Displacement: 6870 cc
Bore × Stroke: 102 × 120 mm
Compression Ratio: 17:1
Starting Method: Electric Start
Lubricating Oil Capacity: 24 L
3. Alternator
Model: 274D
Type: Brushless
Continuous Output: 125 kVA
Power Factor (Cosφ): 0.8
Protection Class: IP23
Insulation Class: H
Automatic Voltage Regulation: AVR AS440
4. Control & Monitoring System
Control Panel: ComAp InteliLite 9
Monitoring Functions:
Current Display: Yes
Frequency Display: Yes
Phase and Neutral Voltage Display: Yes
Power Factor Display: Yes
Automatic Fuel Level Control: Yes
Oil Pressure Alarm: Yes
High Coolant Temperature Alarm: Yes
Battery Voltage Display: Yes
Engine Speed Display: Yes
Engine Hour Counter: Yes
Supervision Features:
Output Relay Monitoring: Yes
LCD Brightness Adjustment: Yes
PIN Code Protection: Yes
Multilingual Support: Yes
5. Alarm & Auto Shutdown Features
High/Low Voltage Alarm: Yes
High/Low Frequency Alarm: Yes
Over/Under Speed Protection: Yes
Low Oil Pressure Alarm: Yes
High Engine Temperature Alarm: Yes
High/Low Battery Voltage Alarm: Yes
Overcurrent Alarm: Yes
Adjustable Start Delay Time: Yes
