PERFORMANCE
Range: From 0 – 1cP to 0 – 10^9 cP over 10 models
Measurement Time: 1 second
Accuracy: 1% of reading or +/- 1 digit
Repeatability: 0.3% of reading or +/- 1 digit
TEMPERATURE
Standard Range: -50 °C to 150 °C
HT Range: -50 °C to 400+ °C
Extended Range: Temperature greater than 150 / 400 °C to order*
PRESSURE
Standard Range: To process fitting
Extended Range: To order for extreme pressure *
PROCESS CONNECTION
Standard fitting: Any process fitting – all flanges, threads, clamps, hygienic
Special fitting: Non-standard process connection to order *
ELECTRICAL CONNECTION
Cable Length: As required – not affected by cable length up to 1000m
Cable Type: Any standard instrument cable
Power: VP Processor powered
SAFETY CERTIFICATION
Hazardous Area: All instruments available for Ex Hazardous Area, explosive atmospheres
Ga Ex ia IIC T1…T6
CONSTRUCTION
All welded, crevice-free
MATERIALS
Head: SS316 ( EN 1.4401)
Fitting: As Required
Sensor: SS316 ( EN 1.4401) and SS316L ( EN 1.4404) as standard
Sensor/Fitting Options: Alloy C22 (EN 2.4602); Alloy C276 (EN 2.4819); S32750 Duplex Steel (EN 1.4410)
Special Materials: Non-standard materials to order *
SURFACE FINISH
Standard: N6 0.8 Ra
Finish Options: Fluoropolymer; Electropolished; Electroplated
Special Finish: Non-standard finish options and coatings to order *
INGRESS PROTECTION
Standard: IP67
SOFTWARE
ViscoLink data viewing and logging PC software
