PERFORMANCE
Range: From 0 – 1cP to 0 – 10^9 cP over 10 models
Measurement Time: 1 second
Accuracy: 1% of reading or +/- 1 digit
Repeatability: 0.3% of reading or +/- 1 digit
TEMPERATURE
Safe Area Range: -50°C to 180°C over 2 models
Ex Range: -50°C to 130°C over 2 models
PRESSURE
Standard Range: To process fitting
Extended Range: To order for extreme pressure *
PROCESS CONNECTION
Standard Fitting: All types of process fitting
Special Fitting: Non-standard process connection to order *
ELECTRICAL CONNECTION
Cable Length: As required – not affected by cable length up to 1000m
Connector: Binder 4-way
Power: VP Processor powered
SAFETY CERTIFICATION
Hazardous Area: All instruments available for Ex Hazardous Area, explosive atmospheres
Ga Ex ia IIC T1…T6
CONSTRUCTION
All welded, crevice-free
MATERIALS
Head: SS316 ( EN 1.4401)
Fitting: As Required
Sensor: SS316 ( EN 1.4401) and SS316L ( EN 1.4404) as standard
Sensor/Fitting Options: Alloy C22 (EN 2.4602)
Alloy C276 (EN 2.4819)
S32750 Duplex Steel (EN 1.4410)
Special Materials: Non-standard materials to order *
SURFACE FINISH
Standard: N7 0.4 Ra
Finish Options: Fluoropolymer; Electropolished; Electroplated
Special Finish: Non-standard finish options and coatings to order *
INGRESS PROTECTION
Standard: IP67
SOFTWARE
ViscoLink data viewing and logging PC software
