Technical Data & Functions
Rated capacity: 225kVA
Input power supply: Single phase 380V; 50Hz
Rated voltage: 25kV
Rated current: 9A
Working Frequency: Power frequency 50Hz
Output voltage Waveform distortion rate: ≤0.5%
Working time: continuous working of 15min under rated load.
Temperature rise: ≤65K after continuous working of 15min under rated load
Quality factor: Q ≥10
Accuracy: 1.5% (RMS)
Protective function: over-current, over-voltage and flashover protections for test object.
Partial discharge amount: ≤5PC
Working Environment
Environmental temperature: -10℃ to 50℃
Related humidity: ≤ 90% RH
Altitude: ≤ 1km
