Max. Output current: AC Single-phase 5000A*3 groups
Circuit mode: Electric voltage regulator with special craft
Duty cycle: 8 hours
AC Input
Phase line: 3P
Voltage: 208V±10%, 60Hz±2% 3Φ4W
Input current: 288A
Output
Phase line: 3Φ4W
Voltage: 0~12V Auto switching
Current:
- AC0~5000A continuous adjustable, stepless speed regulation;
- 3-phase can output at one time, can output single-phase, also can split phase output;
- Tow kinds of output-manual mode and auto mode;
Rated capacity: 180kVA
Stabilized current accuracy: Output current≤±0.5%
Output terminal: Wiring terminal
Protection: The electronic circuit rapidly detects over voltage, over current, over temperature, phase loss, etc., automatic tripping protection and alarm device, the voltage and the current is zero in non-test status.
Accuracy
Source effect: ≤0.3% of rated value
Time drift: ≤1% of rated value
Temp. drift: ≤0.04% of rated value/°C
Load effect: ≤1% of rated value (Output voltage change rate due to the output current change from zero to the rated value.)
Ripple voltage: ≤1% of rated value+10mV
Others
Line regulation: 0.1%
Load regulation: 0.1%
Display and settings
Voltage meter display: True color LCD and digital display instrument (display accuracy: 0.1V display error: ≤1.0%±3 digit)
Current meter display: True color LCD and digital display instrument (5 digits display, display accuracy: 0.1A display error: ≤1.0%±3 digit)
Adjustment setting: Current (High precision potentiometer adjustment)
System
Efficiency: ≥90%
Resistance: Withstand voltage insulation resistance AC1800V 1min, 20MW
Cooling device: Forced fan cooling
Noise: <60dB (1mm in front of the device)
CT accuracy: 0.2%
Protection level: IP20
Working environment
Working mode: Long time temperature rise test
Temperature: -10°C~50°C
Humidity: 0-90% (non-condensing)
Altitude: <1500m
Appearance
Structure: Integration
Dimension: Customized
Weight: Approx. 2.5T
Temperature inspection: 26-way module
A class thermocouple: PT100 with 6m line * 26pcs
