Power supply:
- AC 220V, allowable variation: - 20%~15%; frequency: 50Hz, allowable variation: -4%~2%; waveform: sine wave, distortion factor≤5%;
- DC 110V/220V, allowable variation: -20%~15%; ripple coefficient＜5%;
Interface:
- Ethernet communication
• Model: 10/100Base- Tx;
• Port: 2 pcs;
• Interface type: RJ45;
- Fiber optic Ethernet
• Model: 100Base-FX/1000Base-FX;
• Port: 8 pair;
• Interface type: LC;
- FT3 optical fiber serial port
• Adopted standard: IEC60044-7/8;
• Port: 6pcs for sending,1pcs for receiving;
• Interface type: ST;
- Synchronous interface
• Interface type: ST;
• Timing deviation: < ±1μs;
- Cascading synchronization interface
• Port: 1- way for B code,1- way for RS485 (adaptive master slave mode, can input, output);
• Interface type: phoenix terminal;
Binary output contact
- Quantity: 4 pair;
- Type: idle contact;
- Output capacity: 250V(AC/DC)/0.5A;
- Relay actuation time: < 3ms;
Binary input contact
- Quantity: 8 pair;
- Type: 20~250V(DC) or idle contact;
- Sampling frequency: 10kHz;
- Time resolution: 100μs;
- Anti- jitter time: 0~25ms;
- Timing error: ±0.1ms(0.001s~1s), ±0.01%(1s~1.5x105s);
- Max. timing: 1.5x105s;
Analog small signal input:
- Channel:12;
- Voltage range: ±10V;
- Voltage accuracy: 0.1%;
- Max. current: 1mA;
- Allowable input frequency: sine signal 10~250Hz, transient signal DC~10.0kHz;
- Frequency accuracy: 1mHz;
- Frequency resolution: 0.001Hz;
- Phase accuracy: < 0.1º;
- Status indication: green light means there have signal output;
- Interface type: phoenix terminal;
Analog small signal output
- Channel:12;
- Voltage range: ±10V;
- Voltage accuracy: 0.1%;
- Max.current: 1mA;
- Allowable input frequency: sine signal 10~250Hz, transient signal DC~10.0kHz;
- Frequency accuracy: 0.002%(1mHz under power frequency);
- Frequency resolution: 0.001Hz;
- Phase: phase angle range 0~359.9º, accuracy < 0.1º, resolution ±0.01º(50/60Hz);
- Interface type: phoenix terminal;
Size(W×H×D): 256mm×182mm×365mm;
Weight5kg;
