- AC voltage source output
Range: 6×120 V, 120V/60VA per way
Accuracy: ±10mV at 0.2~2V; ±0.2% at 2V~120V
Resolution: 1mV
- AC current source output
Range: 6×30A, 30A/150VA per way
Accuracy: ±10mA for 0~500mA; ±0.2% for 500mA~30A
Resolution: 1mA
- Output phase
Range: 0~360°
Accuracy: ±0.1°
Resolution: 0.1°
- Output frequency
Range: 0~1000Hz
Accuracy:
<±0.001Hz (0~65Hz)
<±0.01Hz(65~450Hz)
<±0.02Hz (450~1000Hz)
Resolution: 0.001 Hz
- DC voltage source output
Range: 6 way, each way 0~130V/60VA
Accuracy: 0.2%
- DC current source output
Range: 6 way, each way 0~20A/100VA
Accuracy: 0.2%
- IEC 61850 communication interface
Number of ports: 6 pairs are 100M adaptive; 2 pairs are 100/1000M adaptive
Interface Type: LC
Wavelength: 1310nm
- IEC 60044 communication interface
Number of ports: 6 transmit ports, 2 receive ports
Interface type: ST
Wavelength: 850nm
- Synchronization interface
Quantity: 1 GPS/BD ANT; 2 IRIG-B/PPS optical signals: 1 for timing, 1 for time giving; IRIG-B/PPS 2 pairs of electrical signals: 1 pair of timing, 1 pair of time giving; IEEE 1588 1 pair
Interface type: GPS/BD ANT, IRIG-B/PPS optical signal; IRIG-B/PPS electrical signal; IEEE 1588
- Time measurement
Range: 10ms~9999.999s
Accuracy: 1ms
- Switch input
Quantity: 8 pairs
Interrupting Capacity: DC250V/0.5A
- Switch output
Quantity: 6 pairs, of which 2 pairs are for fast opening
- Wireless connection
- Interface Type: WIFI
Wired connection (Ethernet communication interface)
Number of ports: 2
Interface type: 100 megabytes LAN port, RJ45
- Power supply
Supply voltage: AC/DC 220V, allowable deviation: -20%~15%
Supply frequency: 47~65 Hz
- Analog small signal input
Number of channels: 12 way;
Interface Type: Aviation Plug, AC Voltage
- Analog small signal output
Number of channels: 12 way;
Interface Type: Aviation Plug, AC Voltage
- USB interface
Quantity: 2
- Working environment conditions
Working temperature: -20°C~70°C
Humidity: ≤95%, no condensation
- Others
Weight: 15 kg
Size: 360×480×190(mm)
Online interface: RJ45
Display: 10.4 inch 1024*768 true color LCD display with touch function
