• AC Current Output
6-phase (RMS): 6*0~30A
3-phase (RMS): 3*0~60A
6-phase parallel current output (RMS): 0~180A
Allowable long time working value of phase current (RMS): 10A
Maximum output power of phase current: 400VA
Allowable working hours @ max. output of 6-phase parallel current: 10s
Accuracy: <0.2% (within the main range)
Frequency range (Fundamental wave): 0~1000Hz
Harmonic times: 0~20 times
• DC Current Output
Current output: 0~±10A/phase; 0~±60A/6-pahse parallel
Accuracy: 0.2%
Maximum output load voltage: 18V
• AC Voltage Output
Phase voltage output (RMS) 0~120V; Accuracy: 0.2%
Line voltage output (RMS): 0~240V
Phase voltage/Line voltage output power: 80VA/100VA
Frequency range (Fundamental wave): 20~1000Hz
Harmonic times: 1~20 times
• DC Voltage Output
Phase voltage output amplitude: 0~±160V; Accuracy: 0.2%
Line voltage output amplitude: 0~±320V
Phase voltage/Line voltage output power: 70VA/140VA
• Binary
Binary input: 10 channels
Idle contact: 1~20mA, 24V
Potential contact access “0”: 0 ~+6V; “1”: +11 V ~+250 V
Binary output: 8 pairs: DC: 220 V/0.2 A; AC: 220 V/0.5 A
• Time Measuring Range: 0.1ms~9999s; Measuring accuracy: <0.1mS
• Dimension & Weight: 480*360*200mm³; 19kg
