Power frequency AC output
Voltage range (V): 50, 100, 200, 400, 600 (800V is optional), Max. output capacity 20VA
Current range (A): 0.5, 1, 2.5, 5, 10, 20, Max. output capacity 20VA
Voltage adjustment range: 0~130%, fineness adjustment 5*10
Current adjustment range: 0~130%, fineness adjustment 5*10
Accuracy of voltage, current, active power and energy: 0.05%
Accuracy of reactive power and energy: 0.1%
Phase accuracy of current to phase voltage: 0.05°
Frequency:
- Adjustment range: 45~65Hz，
- Fineness adjustment: 0.001Hz
- Setting value accuracy: 0.01Hz
Phase:
- Adjustment range: 0~359.99°
- Fineness adjustment: 0.01°
- Setting value accuracy: 0.05°
Distortion degree of voltage and current output waveform: ≤0.3%
Stability of voltage, current and power output: ≤0.01%/60s (peak-to-peak value)
Harmonics: 2~31 times
Amplitude: 0~20%
Phase fineness: 0.01°*N (“N” refers to harmonic order)
DC output
Voltage range (V): 0.075, 75, 150, 300, 500, 1000, Max. output capacity 20W
Current range (A): 0.5, 1, 2.5, 5, 10, 20, Max. output capacity 20W
Adjustment range of voltage and current: 0~120% (not including 1000V), fineness adjustment 5*10
Stability of voltage and current output: ≤0.01%/60s (peak-to-peak value)
Accuracy of voltage setting value: 0.05%
Accuracy of current setting value: 0.1%
Accuracy at 75mV output (Load ≥5Ω): 0.1%
General parameters
Power supply: Single phase 220V±10%, 50Hz±5%
Use conditions: 20℃±10℃, ≤85%RH
Dimension: 460*460*175mm
Weight: About 20kg
Packing list
Main unit x 1 set
Aluminum alloy box x 1 set
Power cord x 1 pc
Test line with connector x 1 pc
Test line (DC 75mV) x 1 pc
Test line for electric energy pulse x 1 pc
Communication cable x 1 pc
Photoelectric collector x 1 pc
User’s guide x 1 copy
Factory test report x 1 copy
