Specification
Power supply: DC6V alkaline dry battery LR6 (1.5V 4pcs)
Voltage of test line: ＜AC250V
Rated voltage: AC220V
Leakage current step: 15, 30, 50, 75, 100, 150, 200, 250, 300, 500 (unit: mA)
Leakage action time range: 0~999ms
Leakage action time accuracy: ±2ms
Current accuracy: ±5%+2dgt
Failure indication: The LCD displays the “fault” indication due to too small rated action current or the faulty leakage protector.
Test lead: 1.8m
Test mode: Manual / Automatic mode
Display mode: LCD: 128*64 dots
Size: 170*75*30mm
Weight: 290g(with battery); total weight: 350g (with packing box)
Size of LCD: 44*27mm
Battery voltage: When the battery voltage drops to 4.8V, the battery voltage is low, please charge in time. The measurements are also accurate at low battery voltage.
Working current: 40mA Max
Use conditions: -10℃~40℃; <80%RH
Storage conditions: -10℃~60℃; <70%RH
Withstand voltage: ≥100MΩ, AC2kV/rms (between shell and screws)
Standard compliance: IEC1010-1, IEC1010-2-032, pollution degree 2, CAT Ⅲ(600V) IEC61326 (EMC standard)
Accessories
Main unit x 1 set
Carrying bag x 1pc
Probe test line x 1pc
Test line of alligator clip x 1pc
Test line of power socket x 1pc
Packing box x 1pc
Alkaline dry battery (AAA 1.5V) x 4pcs
User’s guide x 1 copy
Warranty card x 1 copy
Factory test report x 1 copy
