Measuring principle90° diffusion ray measuring method (ISO7027 Method)
Measuring range0~5NTU, 0~100NTU, 0~4000NTU
Source of lightLED(860±30nm)
ReproducibilityBelow <±1% F.S
PrecisionBelow <±1% F.S
Minimum scale unit0.0001NTU
Measurement unitNTU, FTU, FNU, mg/L
Applicable temperature0~50℃
Correction methodTwo-point calibiation, zero memory function
Cleaning methodWiper cleaning method, time-setting of cleaning cycle
Screen displayDigital LCD
Output signalSensor : RS-485, monitor : 4~20mA, 0~5V, RS-485, LAN communication(option)
Alarm settingTwo points (high, low), LCD display & buzzer setting
PowerAC 220V, 60Hz, AC 110V(option)
Probe materialExterior : SUS316L, interior: PVC
Weight5kg
Sample insertion &
outflow fitting8mm / 12mm
Cable water-proofIP68 (max. 2m underwater)
Data storage functionMax. 64,000
Self-diagnosis functionLamp, Detector
Cable lengthStandard : 5m( option: orderable)
Measuring chamberSpeed of flow-in: 300~400ml/min recommended
