Test parameters: ALL, UNI.0, UNO.1, V/I
Voltage display:
When set voltage < 135V or 200V
When set voltage > 135V or 200V
Kr display: range 0.000 – 999.9
Sweep current display: range 0.00µA – 2200.0µA
Test speed:
Three levels: Fast 55ms/time, Medium 76ms/time, Slow 112ms/time
Single levels: Fast 25ms/time, Medium 32ms/time, Slow 44ms/time
Leakage voltage measurement accuracy: ≤ ±1%
Voltage display accuracy: 0.5% ± 0.1V
Output resistance: 2kΩ
No-load voltage stability: ≤ ±0.5%
Sweep voltage: 5 – 145V, divided into <135V and >135V ranges
Leakage current range: 0.00µA – 2200.0µA
Leakage current accuracy:
1000.0µA ± 5µA
100.0µA ± 2.0µA
Dimensions: 360 × 325 × 105 mm (W × H × D)
Weight: approx. 6.8 kg
Power supply: 220V ±10%, 50Hz/60Hz ±5%
Operating conditions: 0°C – 40°C, humidity < 90%RH
