Current channel number: Standard six phase
Voltage channel number: Standard six phase
AC current output range: 30A / phase or 180A (six phase parallel)
DC current output range: 10A DC /phase
AC voltage output range: 120V AC /phase
DC voltage output range: 160V DC / phase
AC current output
The virtual value of each phase output when six phase current output 0 ～30A output precision 0,2 grade
The virtual value of each phase output when three phase current output 0～60A
The virtual value of six phase parallel current output 0～180A
The allowed virtual value when the phase current work long time 10A
The maximum output power of phase current 450VA
The maximum output power when six phase parallel current output 1000VA
The allowed working time when six phase parallel current maximum output 10s
Frequency range（fundamental wave） 0～1000Hz
Harmonic order 0～20
DC current output
Current output 0～±10A / phase output precision 0,2 grade
The maximum load volatage output 20VAC voltage output
The virtual value of phase voltage output 0～120V output precision 0,2grade
The virtual value of line voltage output 0～240V
The output power of phase voltage/ line voltage 80VA / 100VA
Frequency range（fundamental wave） 0～1000Hz
Harmonic order 0～20
DC voltage output
The output amplitude of phase voltage 0～±160V output precision 0.2 grade
The output amplitude of line voltage 0～±320VThe output power of phase voltage/ line voltage 70VA/ 140VA
Input and output
8 channels input
Free contact 1～20mA，24VElectric potential contacts “0”：0 ～ +6V；“1”：+11 V ～+250V
4 channels output DC：220 V／0.2 A；AC：220 V／0.5A
Time measurment range
0.1ms ～ 9999s ， measurement accuracy ＜0.1ms
