Measuring Range
Output current: 100A, 80A, 50A, 30A
Measuring range:
0~2000µΩ
80A 0~5mΩ
50A 0~10mΩ
30A 0~20mΩ
Technical Index
Accuracy: ±（Reading×0.5%+1µΩ）
Resolution ratio: 0.1µΩ
Display digit: four and a half
Test power supply: Constant current limit voltage，about 2V
Input voltage: Maximum 5V
Measuring time: Quick, 10~60 seconds optional
Testing times: More than 600 times（full charge, fast measurement mode）
Test line: Resistance less than 10mΩ
Conditions Of Use and Shape
Working power supply: Built-in lithium battery or external charger，Charger input 100~240VAC，50HZ/60HZ
Charging voltage: 12.6V
Charging current: ≤3A
Charging time: About 3 hrs
Auto shut off: 5 minutes automatic shutdown without operation
Instrument weight: 1.7kg（exclude test lines）
Instrument dimension: 246mm（L）×156mm（W）×62mm（H）
Environment temperature: -10℃~50℃
Relative humidity: ≤90%，no dew
